Overview
Multifect-LX is a single channel eddy current comparator for segregation of metallic components and raw stock.
Applications
- Sorting of bars or components according to alloy type
- Sorting of fasteners according to hardness
- Segregation of forgings as per heat-treat condition
- Evaluation of gudgeon pins for case-depth
Features
- Single frequency tests
- Automatic sorting
- Windows Professional operating system
- Extensive Data logging and reporting
- Circular, Box or rectangular thresholds
Technical Data
Frequency Range 100 Hz to 100 KHz
Signal Gain 0 dB to 80 dB in steps of 0.1 dB
Phase 0 deg to 359 deg in steps of 1 deg
Thresholds Rectangular: Two vertical, two horizontal
Circular, Box
Part-in detection / Test trigger
Automatic or external
Tests available Single frequency sorting
Features
- Single frequency tests
- Automatic sorting
- Windows Professional operating system
- Extensive Data logging and reporting
- Circular, Box or rectangular thresholds
Technical Data
Frequency Range: 100 Hz to 100 KHz
Signal Gain: 0 dB to 80 dB in steps of 0.1 dB
Phase: 0 deg to 359 deg in steps of 1 deg
Thresholds: Rectangular: Two vertical, two horizontal Circular, Box
Part-in detection / Test trigger: Automatic or external
Tests available: Single frequency sorting
